Automatic Hand Dryer 120 Volt (1187)

Frost’s 1187 120-volt automatic hand dryer is a durable and reliable solution for high-traffic Canadian commercial environments. Ideal for schools, universities, recreation centres, hospitals, fitness facilities, and airports across Canada, this unit’s touchless operation, robust aluminum construction, and affordable price point make it a popular choice for efficient hand drying.

Features

• Canadian made with cast aluminum
• Touchless operation with a 10–30 cm (4–12″) sensor range
• Approximately 20-second drying time with 20.5 m/s wind velocity
• Quiet operation at 61–67 dB
• Certifications: UL (Canada, enhanced mark), CE, EMC, LVD, WEEE, ROHS
• Can be hard-wired or plugged in with included 9' AC adapter

Specifications

• Product Code: 1187
• Product Name: Automatic Hand Dryer 120 Volt
• Single Carton UPC: 624622118709
• Single Carton Shipping Dimensions: 25.4 cm L x 20.3 cm W x 35.6 cm H (10″ L x 8″ W x 14″ H)
• Single Carton Shipping Weight: 7.3 kg (16.0 lbs)
• Operation: 120 volts, 2200 watts, 161 cfm (274 m³/h), 100-watt brushless motor at 3,450 rpm
• Materials: Cast aluminum, painted white finish
• Product Dimensions: 33.0 cm W x 22.2 cm H x 18.3 cm D (13″ W x 8.75″ H x 7.2″ D)
• Product Weight: 6.8 kg (15.0 lbs)

What models of hand dryers does Frost Products Ltd. offer for commercial use?

Frost Products Ltd. offers high-speed, touch-free hand dryers for commercial washrooms, including:

• 1187: Automatic, white epoxy cast aluminum, 2200W, 20-second drying time.
• 1192, 1193: High-speed, stainless steel, designed for high-traffic areas, with blue LED targeting.
• 1194, 1195, 1196, 1198: Eco-friendly, compact models (stainless steel, white, or black epoxy), 1000W, 10–15-second drying time, ideal for renovations.

What are the key features of Frost’s high-speed hand dryers?

Frost’s hand dryers (1192, 1193, 1194, 1195, 1196, 1198) feature:

• Fast Drying: 7–15 seconds, with 1192/1193 rivaling the fastest in the industry.
• Touch-Free Operation: Infrared sensors (6–7” range) ensure hygienic use.
• Durable Construction: 18-gauge stainless steel (1194, 1195, 1196) or drawn steel with white/black epoxy (1195, 1198).
• Certifications: UL, CE, EMC, LVD, WEEE, ROHS, GreenSpec, and ISO 14025 EPD certified for safety and environmental compliance.

How energy-efficient are Frost hand dryers?

Frost’s eco-friendly models (1194, 1195, 1196, 1198) use 1000W (500W heating element, 0.5W standby), earning LEED credits for energy performance (EA Prerequisite 2, EA Credit 1). The 1187 model uses 2200W but offers efficient 20-second drying. All models operate on 110–120V, 50/60Hz, with 8.4–14.5 amps, minimizing energy costs in high-traffic settings like schools and restaurants.

What are the installation requirements for Frost hand dryers?

• Mounting Height: Install 12” (30cm) above fixed/movable objects, with the bottom not exceeding 48” (120cm) from the floor for ADA compliance.
• Hardware: Includes mounting template, screws, and anchors; use a level and screwdriver/drill for installation.
• Electrical: Hard-wired or plugged in (AC adaptor included for 1194, 1195, 1196, 1198); requires 15-amp circuits for eco models. Installation by a qualified electrician is required to maintain the 5-year warranty. Contact Frost for detailed instructions.

How should Frost hand dryers be maintained to preserve warranty coverage?

Wipe exterior with a damp soft cloth or approved stainless steel cleaner (for 1192, 1193, 1194, 1195, 1196). Avoid bleach, acids, or chlorides to prevent discoloration. Keep motor and internal parts free of excessive dirt, dust, or debris. Failure to maintain may void the 5-year warranty. Train maintenance staff to use proper cleaning agents to avoid damage.

Are Frost hand dryers suitable for high-traffic commercial environments?

Yes, Frost hand dryers are designed for high-traffic areas like schools, universities, hospitals, fitness facilities, restaurants, and airports. Models 1192 and 1193 are built for maximum durability, while compact eco models (1194, 1195, 1196, 1198) suit renovations with limited space. The 1196 supports up to 35,000 hand dries per battery set, ideal for busy washrooms.

What are the material and finish options for Frost hand dryers?

• 1187: Cast aluminum with white epoxy finish.
• 1192, 1193: Stainless steel (type not specified, likely 304 or 430).
• 1194: 18-gauge stainless steel, chrome finish.
• 1195, 1196: 18-gauge drawn steel, white powder coat.
• 1198: 18-gauge drawn steel, black epoxy finish. All finishes are durable and resistant to rust when properly maintained.

Are Frost hand dryers compliant with accessibility and environmental standards?

Yes, models 1194, 1195, 1196, and 1198 are ADA compliant when installed at the recommended height (bottom ≤48”/120cm from floor). All models meet UL, CE, EMC, LVD, WEEE, and ROHS standards, with 1194–1198 earning LEED credits for energy efficiency (EA Prerequisite 2, EA Credit 1). The 1192 and 1193 also carry GreenSpec and ISO 14025 EPD certifications for environmental performance.

Shipping, Returns, Warranty for Frost Products Ltd.

Shipping

All Frost Products Ltd. orders are shipped FOB from our facility at 5276 John Lucas Drive, Burlington, Ontario, Canada, L7L 5Z9. Orders are processed within 48 hours of receipt, and we strive to ship within this timeframe, though rush orders are not guaranteed. Claims for damaged goods or shortages must be reported to Frost within 5 business days of shipment.

Returns

Standard Frost products may be returned within 12 months of the invoice date, subject to a 20% restocking fee. Additional handling or repacking charges may apply upon inspection. A Return Goods Authorization (RGA) is required before returning any product, and unauthorized returns may be refused. Custom products are non-returnable. To initiate a return or obtain an RGA, contact info@facilitysupplypro.com with your order details.

Warranty

Frost Products Ltd. offers comprehensive warranties for our commercial washroom products:

• General Warranty: All products are covered for 12 months from the date of shipment. Defective products or parts will be repaired or replaced at no charge, including freight costs, when authorized by Frost. Costs for installation or removal are not covered. Discoloration of stainless steel parts due to harsh environmental conditions or chemical exposure (e.g., bleach, acids) is not considered a defect and is not covered.
• Mirror Warranty: Frost mirrors, including vandal-resistant channel frame, frameless, and barrier-free tilt designs, are covered by the 12-month general warranty. Mirror glass, conforming to GS12GD5A type 1B, is guaranteed against silver spoilage for 10 years. Tempered mirrors may show slight distortion when viewed from a distance, which is not a defect. Damage from improper cleaning (e.g., using ammonia, vinegar, bleach, or solvents) is not covered. Use mild, non-ammonia-based cleaners with a damp cloth, avoiding direct spraying to prevent edge contamination.
• Hand Dryer Warranty: Frost hand dryers carry a 5-year warranty from the date of purchase, covering the motor assembly and all working parts. Units must be kept free of excessive dirt, dust, or debris to maintain warranty validity. Failure to perform proper maintenance may void the warranty. For warranty claims, contact Frost Products Ltd. to obtain a Return Goods Authorization (RGA). Regular maintenance, such as wiping products with a damp cloth and using approved stainless steel cleaners, ensures optimal performance and preserves warranty coverage. Avoid harsh detergents or chemical cleaners on stainless steel surfaces.
